Acrylic Beam Spoiler, 0.375" (0.95 cm) Thick.
Beam spoilers are primarily used in radiation therapy to alter a high-energy radiation beam before it reaches the patient by increasing the surface dose by generating lower-energy secondary electrons in the beam path. This reduces the usual “skin-sparing” effect of high-energy photon beams, which is useful when the treatment target includes the skin or near-surface tissue, such as in total body irradiation or some head/neck and breast treatments.
The Beam Spoiler is used on Frame 495-004. The Beam Spoiler is available in acrylic or polycarbonate in 0.375" (0.95 cm) or 0.50" (1.27 cm) thickness. The beam spoiler has two key holes on both the 60" (152 cm) side and on the 84" (213.4 cm) side to allow for positioning on the frame in either direction. The key holes can also be used to hang the beam spoiler from wall hooks for storage.
Compatible with:
- Beam Spoiler Frame for TBI with Short, Top & Bottom Bars Conversion (Item # 495-010 w/ 495-012)
- Beam Spoiler Frame for TBI (Item # 495-010)
Specifications
Size: 60" x 84" (152.4 x 213.4 cm)
Density: 1.185 g/cc
Thickness: 0.375" (0.95 cm)
Weight: 77 lb (35 kg)
All RPD Beam Spoilers
| Item # | Material | Width | Height | Thickness | Rotatable | Intended Use |
| 495-005 | Polycarbonate | 60" (152.4 cm) | 84" (213.4 cm) | 3/8" (0.95 cm) | Yes | Beam Spoiler Frame |
| 495-006 | Polycarbonate | 60" (152.4 cm) | 84" (213.4 cm) | 1/2" (1.27 cm) | Yes | Beam Spoiler Frame |
| 495-007 | Acrylic | 60" (152.4 cm) | 84" (213.4 cm) | 3/8" (0.95 cm) | Yes | Beam Spoiler Frame |
| 495-008 | Acrylic | 60" (152.4 cm) | 84" (213.4 cm) | 1/2" (1.27 cm) | Yes | Beam Spoiler Frame |
| 495-600-84 | Polycarbonate | 38" (96.5 cm) | 86" (218.4 cm) | 3/8" (0.95 cm) | No | Fixed TBI Stands |
| 495-600-86 | Polycarbonate | 38" (96.5 cm) | 86" (218.4 cm) | 1/2" (1.27 cm) | No | Fixed TBI Stands |
| 495-600-83 | Acrylic | 38" (96.5 cm) | 86" (218.4 cm) | 3/8" (0.95 cm) | No | Fixed TBI Stands |
| 495-600-85 | Acrylic | 38" (96.5 cm) | 86" (218.4 cm) | 1/2" (1.27 cm) | No | Fixed TBI Stands |
| 495-605-84 | Polycarbonate | 42" (106.7 cm) | 96" (243.8 cm) | 3/8" (0.95 cm) | No | Rotational TBI Stands |
| 495-605-86 | Polycarbonate | 42" (106.7 cm) | 96" (243.8 cm) | 1/2" (1.27 cm) | No | Rotational TBI Stands |
| 495-605-83 | Acrylic | 42" (106.7 cm) | 96" (243.8 cm) | 3/8" (0.95 cm) | No | Rotational TBI Stands |
| 495-605-85 | Acrylic | 42" (106.7 cm) | 96" (243.8 cm) | 1/2" (1.27 cm) | No | Rotational TBI Stands |
